JK6836BT bluetooth usb tf fm mp3 module
1, Functions: Bluetooth/USB/TF/ MP3 /Line in (AUX)/FM
Format:MP3/WMA/MAV.
MP3 decorder support 32–320kbps
FAT16 or FAT32 systems supported
4 Keys: MODE, NEXT/V+, PLAY/PAUSE/SCAN, PRE/V-
With Remote control
2, When power on, firstly read MP3 songs of USB/TF storage, without USB/TF device under AUX mode, press “MODE” switch to “USB/TF/AUX”.
3, This decoder has 4 keys.
MODE: USB/TF/AUX/FM switch.
Long press 3 seconds for power ON/OFF
NEXT/V+: Under MP3 mode, short press NEXT, long press VOL+.
Under AUX mode, press VOL+.
Under FM mode, short press to selection up, long press VOL+.
PLAY/PAUSE: Under MP3 mode, short press PLAY/PAUSE, long press STOP..
Under AUX mode, press PLAY/PAUSE.
Under FM mode, short press to automatic selection.
PRE/V-: Under MP3 mode, short press LAST, long press VOL-.
Under AUX mode, press VOL-
Under FM mode, short press to selection down, long press VOL-.
4, Power supplyDC5V( Optional 12V)
5, LED display
6, With IR remote control
7.Size: 105*25.5mm
Applications :
HI-FI system , MP3 amplifier , Boom Box ,embedded Audio systems
